Zund M800 samplemaker
€21.500,00
ZUND M-800, digital cutter and sample-maker, loacted in our Workshop in Kirchheim unter Teck, Germany
Machine has only 1760 production hours
| Plotting area | 1300 x 800 mm² | |||
| Dimensions (W x D x H) | 1840 x 1240 x 800 mm | |||
| Weight | 250 kg | |||
| Maximum speed | 750 mm/s | |||
| Acceleration | 5 m/s² | |||
| Resolution | 0.005 mm | |||
| Addressable resolution | 0.01 mm | |||
| Static repeatability | ± 0.02 mm | |||
| Software-interface | ASCII Extended HP-GL command set |
|||
| Hardware-interface | RS232C/V24 (600...38200 Baud) | |||
| Input-Buffer | 1 MB | |||
| Mains connection | 100 VAC ± 10% 115 VAC ±10% 230 VAC ±10% 50/60 Hz |
|||
| Power consumption | 700 VA | |||
Numéro de l'article 36105
Condition
(5) Very good condition, almost newIn production
Ready to be delivered
Marque
Zund
Disponibilité
Immediately
Année de construction
