WPM 400C

Here are the technical specifications of the machine:

Machine Designation: WPM 400C

Technical Specifications

Punching Force Max.: 4000 kN (= 400 t)

Punching Force: Adjustment: Approx. 5‰ - 995‰, continuously adjustable

Sheet Format Max.: 820 x 1125 mm

Sheet Format Min.: 360 x 400 mm

Technical Punching Area Max. incl. Gripper: 800 x 1115 mm

Gripper: Standard 15 mm

Inner Closing Frame Width: 820 x 1134 mm

Punch Die Size: 812 x 1125 mm

Waste Removal Station Available (Waste)? Yes

Product Separation Possible (Separating)? Yes

System / Sheet Alignment: A and B side

Tolerance Range: ±1 mm

Materials: Paper, cardboard, solid and corrugated board

Area-Related Mass: 80 - 2000 g/m²

Material Thickness Max.: 6.0 mm

Minimum Speed: 1500 sheets/h

Maximum Speed: 9000 sheets/h

Max. Stack Height Feeder incl. Pallet: 1100 mm

Max. Stack Height Delivery incl. Pallet: 1000 mm
